Quick Details

  • Place of Origin: Fujian, China (Mainland)
  • Brand Name: kubota
  • Model Number: GF2-K15
  • Output Type: AC Three Phase
  • Speed: 1500/1800rpm
  • Frequency: 50HZ/60HZ
  • Rated Power: 12kw
  • Rated Voltage: 400/230V
  • Rated Current: Depend
  • Engine: Japan Kubota D1703
  • Alternator: Stamford PI044G
  • Control Panel: Smartgen, ComAp, Deepsea,Harsen
  • Fuel Tank Capacity: 8-10hours
  • Warranty: 12 Months/1000 Hours
  • Type: Ultra-Silent
  • Certificate: CE/ISO9001
  • Options: ATS, Open Frame, Trailer Type
  • Keyword: KUBOTA DIESEL GENERATOR

Packaging & Delivery

Packaging Details wooden case&plywood case
Delivery Time 20days
Product Description

 50Hz 6kw-30kw power with Japan Kubota Diesel Generator

Kubota  diesel generator  widely used in the area of industry, railway and construction. The engine is imported from Japan. The global service net of Superwatt and Kubota can provide our customers with reliable and guaranteed service.



Diesel generator set power  with Japan Kubota engine and Stamford/ Leorysomer / Marathon / Meccalte alternator



Our company provides a full line of brand new and high quality products which are strictly tested before shipment.

Quality warranty is according to our standard conditions: 1year or 1500hours



12kw 15kva diesel generator Japanese Kubota Engine D1703 low fuel consumption  with Stamford Alternator

Generator set

GENSET TYPERATEDSTANDBYENGINEALTERNATOR
KW/KVAKW/KVAMODELMODEL
GF2-K86/7.56.6/8.3D905PI 044D
GF2-K118/10.08.8/11.0D1105PI 044E
GF2-K15 10.8/13.512/15.0V1505PI 044F
GF2-K1712/15.013/16.5D1703PI 044F
GF2-K2317/21.219/23V2203PI 044H
GF2-K2820.6/25.723/28V2003-TPI 144D
GF2-K3827.5/34.430/38V3300PI 144G
GF2-K4734/42.537/47V3300-TPI 144H





prime Power:
This rating is for the supply of continuous electrical power (at variable load). There is no limit on the annul hours of operation and 10% overload power can be supplied for 1 hour in 12.
Standby Power:
This rating is for the supply of continuous electrical power (at variable load) in the event of a utility power failure. No overload is permitted.
Rated Voltage:
Available with customer requirements.

Kubota  Engine





Alternator

Other alternator option: Leroy Somer



Control System
Harsen GU601A Genset Controller
Description:
The GU601A is an Automatic Start Control Module designed to automatically start and stop the Generator.The module also monitors and protects the engine, indicating operational status, fault conditions and metering on the front panel LCD and LED’s.
1.Configuration of parameters by front panel push buttons or by PC via mini USB interface with license free software.
2.Configurable fuel output energise to stop energise to run.
3.3Configurable inputs.
4.3 Configurable outputs.
5.2 Analogue inputs configurable for different senders for oil pressure and engine temperature.
6.True RMS measuring
