Quick Details

  • Place of Origin: China (Mainland)
  • Output Type: AC Three Phase
  • Speed: 1500rpm/1800rpm
  • Frequency: 50HZ/60HZ
  • Rated Power: 10-1000kw, 10-3000kw
  • Rated Voltage: 230/400V
  • Rated Current: 18-1080A
  • Fuel: natural gas, methane,biogas,CNG,LNG
  • Alternator Model: MeccAlte,Stamford, Leroy Somer
  • Controller: Deep sea DSE series, Comp
  • Type: Silent, container, CHP, CCHP

Packaging & Delivery

Packaging Details Poly plastic foam or wooden case
Delivery Time 20days

Manufacturer supply for 20 years
Power sypply range: 10kw-1100kw
Continious supply range: 8kw-900kw
Large power available by parallel system:EG: 2MW.5MW...
Standard componient and assembly
Multi-option of control panel
With CE and ISO certificate





1. 100KW technical specification of natural gas gensets



Genset data

Genset Model

HR100GF-NG

 (Rated power)(KW)

100

 (Voltage)(V)

400

(Frequency)(HZ)

50

(Rated current)(A)

180

Dimension (mm)

3000*890*1566

Weight (kg)

2000

Engine

Gas Engine Model

Ricardo /Weichai

Engine number

6126ZLD

(Type)

(Vertical in-line, water cooling,4-stroke)

(mm) (Cylinder NO.-Bore*Stroke)

4-100×121

(Displacement)(L)

9.726

(Rated power/speed)(KW/min)

20/1500

(Working condition of calibration gas consumption rate0(m³/KW.h)

(Natural gas)≤0.33m³/kw.h (Methane)≤0.55m³/kw.h

(Mode of speed regulation)

(Electronic Governor)

(Mixture-formation form):

(Before the vortex premixed)

Fuel type

Natural gas/Methane/Straw gas/Rock gas

Start method

(Electrical start)

Alternator

(Rated power)(KW)

100

(Rated Voltage)(V)

400

(Rated current)(A)

180

(Rated frequency)(HZ)

50

(Rated capacity)(KVA)

125

(Exciting mode)

(Brushless)

(Insulation class)

H

(IP code)

IP21

(Connection mode)

Three phase four wire

Date of production

January, 2016

Condition

New and clean

Inspector





 2.

Genset data

Genset Model

HR100GF-NG

 (Rated power)(KW)

100

 (Voltage)(V)

400

(Frequency)(HZ)

50

(Rated current)(A)

180

Dimension (mm)

3000*890*1566

Weight (kg)

2000

Engine

Gas Engine Model

Ricardo /Weichai

Engine number

6126ZLD

(Type)

(Vertical in-line, water cooling,4-stroke)

(mm) (Cylinder NO.-Bore*Stroke)

4-100×121

(Displacement)(L)

9.726

(Rated power/speed)(KW/min)

20/1500

(Working condition of calibration gas consumption rate0(m³/KW.h)

(Natural gas)≤0.33m³/kw.h (Methane)≤0.55m³/kw.h

(Mode of speed regulation)

(Electronic Governor)

(Mixture-formation form):

(Before the vortex premixed)

Fuel type

Natural gas/Methane/Straw gas/Rock gas

Start method

(Electrical start)

Alternator

(Rated power)(KW)

100

(Rated Voltage)(V)

400

(Rated current)(A)

180

(Rated frequency)(HZ)

50

(Rated capacity)(KVA)

125

(Exciting mode)

(Brushless)

(Insulation class)

H

(IP code)

IP21

(Connection mode)

Three phase four wire

Date of production

January, 2016

Condition

New and clean

Inspector





60KW-300KW NATURAL GAS GENERATOR TECHNICAL DATA



Engine ModelCylinder No.Rated PowerOverload PowerRated SpeedFuel Consumption

R6105D-NG660kw/81.6hp66kw/90hp1500rpm224g/kw.h
R6105ZD-NG684kw/114hp92.4kw/125.7hp1500rpm224g/kw.h
R6105AZD-NG690kw/122hp99kw/134.7hp1500rpm224g/kw.h
R6105ZLD-NG6100kw/136hp110kw/150hp1500rpm224g/kw.h
R6105AZLD-NG6110kw/150hp121kw/165hp1500rpm224g/kw.h
R6110IZLD-NG6132kw/180hp145.2kw/198hp1500rpm224g/kw.h
HR6110ZLD-NG6150kw/204hp165kw/224hp1500rpm224g/kw.h
R6113ZLD-NG6155kw/210hp170.5kw/232hp1500rpm224g/kw.h
HR6126ZLD-NG6230kw/313hp253kw/344hp1500rpm208g/kw.h
HR618D-NG6300kw/4o8hp330kw/450hp1500rpm208g/kw.h
