Quick Details

  • Place of Origin: China (Mainland)
  • Output Type: AC Three Phase
  • Speed: 1500rpm/1800rpm
  • Frequency: 50HZ/60HZ
  • Rated Power: 10-1000kw, 10-3000kw
  • Rated Voltage: 230/400V
  • Rated Current: 18-1080A
  • Fuel: natural gas, methane,biogas,CNG,LNG
  • Alternator Model: MeccAlte,Stamford, Leroy Somer
  • Controller: Deep sea DSE series, Comp
  • Type: Silent, container, CHP, CCHP

Packaging & Delivery

Packaging Details Poly plastic foam or wooden case
Delivery Time 7-15 Working days after receving the deposit

Manufacturer supply for 20 years
Power sypply range: 10kw-1100kw
Continious supply range: 8kw-900kw
Large power available by parallel system:EG: 2MW.5MW...
Standard componient and assembly
Multi-option of control panel
With CE and ISO certificate





1. Main technical specification of natural gas gensets



Engine ModelCylinder No.Rated PowerOverload PowerRated SpeedFuel Consumption

R6105D-NG660kw/81.6hp66kw/90hp1500rpm224g/kw.h
R6105ZD-NG684kw/114hp92.4kw/125.7hp1500rpm224g/kw.h
R6105AZD-NG690kw/122hp99kw/134.7hp1500rpm224g/kw.h
R6105ZLD-NG6100kw/136hp110kw/150hp1500rpm224g/kw.h
R6105AZLD-NG6110kw/150hp121kw/165hp1500rpm224g/kw.h
R6110IZLD-NG6132kw/180hp145.2kw/198hp1500rpm224g/kw.h
HR6110ZLD-NG6150kw/204hp165kw/224hp1500rpm224g/kw.h
R6113ZLD-NG6155kw/210hp170.5kw/232hp1500rpm224g/kw.h
HR6126ZLD-NG6230kw/313hp253kw/344hp1500rpm208g/kw.h
HR618D-NG6300kw/4o8hp330kw/450hp1500rpm208g/kw.h



Generating set general Model

HR80GF

Structure

integral

Exciting method

AVR Brushless

Rated Power (kVA/kW)

100KVA/80KW

Rated Current(A)

1440

Rated Voltage(V)

400/230

Rated Frequency(Hz)

50

Rated Power Factor

0.8 LAG

Overall dimension (L x W x H)(mm)

1320X600X900

Net weight (kg)

500

Gas Engine

Model

NQ15D1.5

Type

In line 4stroke, electric control ignition, pre-mixed stoichiometry burn

Cylinder number

3

Bore x Stroke (mm)

80x90

Total displacement (L)

1.5

Rated Power (kW)

15

Rated Speed (r/min)

1500

Fuel type

Natural gas

Control panel

NPT Brand10 KZY

LCD display

Circuit Breaker type

  ATS SKT1-20

Control Module

Smartgen

Operation language

English

Alternator

Model

XN164C

Brand

MBH( Germany brand)

Shaft

Single bearing

Rated Power (kW)

10.8

Rating(kVA)

13.5

Enclosure protection

IP23

Efficiency (%)

80
